The application of insulated steel silos in long-term grain storage

Aug.08, 2025Keywords:insulated steel silos, grain steel silos, insulated grain storage silos

With global climate change and the increasing emphasis on food security, the long-term storage of grain has become a key concern. In many tropical regions and during hot seasons, steel silos, due to their strong thermal conductivity, heat up grain quickly, making it difficult to maintain a stable temperature. This directly impacts grain quality and safety, making them impractical for long-term storage. Effectively controlling silo temperature and humidity to maintain the high quality of grain has become a pressing challenge for the industry. To address this, Sron, leveraging its accumulated experience in silo engineering and rigorous calculations, has developed innovative insulated steel silos, providing a reliable solution for long-term grain storage.

How Insulated Steel Silos Work

Traditional steel silos often face challenges such as the steel's high thermal conductivity, rapid temperature rise near the silo walls under sunlight, and increased insect infestation within the silo. This makes the grain susceptible to environmental influences and prone to spoilage over extended periods. To address this issue, Sron Company utilizes insulated steel silos for long-term grain storage with temperature requirements. The core technologies of this storage system are twofold. First, a layer of insulation material, such as polyurethane and polystyrene board, effectively isolates the grain from external heat, preventing heat transfer and ensuring stable temperature and humidity within the silo. Second, the insulation layer is strategically and rationally installed with a keel that provides sufficient strength to support the insulation layer while minimizing the formation of cold bridges and reducing the transfer of heat from the protective layer to the interior.

Working Principle:

External Insulation: A suitable thickness of polyurethane insulation material (thermal conductivity ≤ 0.024) is applied to the exterior of the steel silo, significantly reducing heat transfer from external heat and slowing the temperature rise of the grain within. Grain Cooler Circulation System: A ventilation trough is installed inside the silo, and grain cooling return ducts are installed on the silo walls. The grain cooler ventilates the silo through the ventilation trough, slowly dispersing the cool air inside. Warmer air from the silo ceiling passes through the grain cooling return duct, where it is cooled and dehumidified in the grain cooler before being returned to the silo to cool the grain. This fully utilizes the cooler air exhausted from the silo, reducing the grain cooler's energy consumption and creating a highly efficient and energy-saving temperature control system.

Intelligent Temperature Control System: The silo's grain status system monitors temperature changes in real time. If the grain temperature rises above a certain level, an alarm will be triggered, prompting personnel to take appropriate measures.

Advantages of Insulated Steel Silos

1. Smooth Temperature Changes Ensure Long-Term Grain Storage Quality

Insulated steel silos are designed to effectively prevent heat loss and temperature fluctuations. Slow temperature rise and stable grain temperature within the silo are key to ensuring long-term grain storage and preventing insect infestation and mold.

2. Patented Technology Significantly Improves Insulation Performance

Sron's insulated steel silo technology successfully prevents heat exchange between the silo and the outside, significantly improving insulation performance. Compared to other traditional storage systems, the heat transfer area of a 10,000-ton silo is only 0.18 square meters, less than 2% of that of other suppliers. This means that under the same environmental conditions, insulated steel silos provide more efficient insulation and heat preservation.

3. Low Investment, High Cost-Effectiveness

Compared to traditional concrete silos, insulated steel silos require significantly lower construction investment. Their insulation benefits come from high-efficiency insulation materials such as polyurethane foam, polystyrene board, and fiberglass, making them highly economical. Concrete silos, by comparison, are significantly more expensive to construct and maintain.

Sron's Technical Advantages and Comprehensive Services

1. EPC General Contracting Capabilities, Comprehensive Solutions

Sron boasts strong EPC general contracting capabilities, enabling us to provide clients with safe, reliable, and technologically advanced steel silo engineering systems, ranging in capacity from 50 to 125,000 tons. We offer comprehensive services, from complete process design to civil foundation design, including system solutions for conveying, cleaning, ventilation, dust removal, drying, metering, temperature measurement, fumigation, and insulation, providing clients with one-stop EPC general contracting services.

2. Professional Technical Team, Driven by Innovation

The company boasts a strong technical team, comprised of seven senior engineers and over 28 professional technicians, including first-class registered architects, first-class registered structural engineers, and first-class registered construction engineers. We fully understand the importance of technological innovation to industry development and have obtained over 100 patents and participated in the drafting of four national and industry standards. Sron, driven by technological innovation, continuously promotes industry advancement.

3. Strong Manufacturing Capabilities

The company operates three manufacturing bases equipped with advanced production lines, achieving an annual manufacturing capacity of 30,000 tons. We have successfully completed more than 1,000 steel silo projects in more than 40 countries and regions, including Russia, Egypt, Indonesia, Malaysia, Kenya, etc., with a total storage capacity of more than 3 million tons, winning unanimous praise from domestic and foreign customers.

As the impacts of climate change intensify, the long-term safe storage of grain becomes even more crucial. Sron's insulated steel silos, with their advanced insulation technology, energy-efficient operation, and economical and practical design, have become an ideal choice for grain storage. Whether in hot or humid environments, these insulated steel silos effectively ensure the long-term safe storage of grain and maintain consistent grain quality.
