AIR CUSHION CONVEYOR

Product Information :
Air-cushion belt conveyor is advanced technology using gas film supporting the conveyor belt. Ideal for silo roof grain conveying for its low equipment weight load and big capacity.

Product Information

Air-cushion Belt Conveyor

For its low self structure weight and big conveying capacity, and advantage of low down silo roof load bearing, air-cushion belt conveyor is widely used for big capacity conveying for grain in industries of food workshop,grain terminals, sea ports depot, mining, coal, chemical industry, steel etc.

  • The air-cushion belt conveyor use thin film replacing the roller, which greatly improve the operation situation of the belt and reduce the frictional resistance.
  • You are optional for single chamber or double chamber according to the demand.
  • Fully-enclosed structure, small dust, low noise, environment-friendly.
  • The tail adopts the sealing type self-cleaning feed recycle device, fundamentally solve the tail material-accumulation problem.
  • Equip with inspection door, observation window, dust-collection exhaust inlet, keep watching on the equipment running status.
  • Optional for speed detection, misalignment, anti-blockage, scram detection device etc., assure the machine safety and efficient.

Technical Specifications

Model Capacity(t/h) Line Speed(m/s) Conveying Belt
Width(mm)
TDSQ50 90-170 1.6-2.5 500
TDSQ65 150-230 1.6-2.5 650
TDSQ80 330-480 1.6-3.15 800
TDSQ100 500-750 1.6-3.15 1000
TDSQ120 780-1100 1.6-3.15 1200
TDSQ140 1070-1500 1.6-3.15 1400
TDSQ160 1600-2200 1.6-3.15 1600
